CFN-02 LED II 3D Ex tc IIIC T70˚ Dc

The CFN-02 LED lighting fixture is intended for use in humid or dusty environments, with a conductive dust atmosphere in zone 22. Ambient temperature: -25°C to +45°C (5°C to +45°C with emergency kit).

Add to list
Filtrare

Models:

Description

The fixture is made of UV-stable polycarbonate, with high impact and deformation resistance, and is resistant to dust, moisture, and water jets.
The diffuser is made of transparent UV-stable polycarbonate, with a prismatic internal structure to ensure even light distribution.
The reflector is made of steel sheet.
The mounting bracket is made of polyamide with fiberglass.
The diffuser lock is made of stainless steel and polyamide with fiberglass, which remains fixed to the fixture when opened.
Screw-in cable entry: PG13 ATEX.
Permitted cable diameter range: Φ7÷Φ13 mm.
Maximum conductor section: 2.5 mm².
3-pole connector with grounding.
Explosion protection: II 3D Ex tc IIIC T70°C Dc
tc – protection against dust ignition via the housing.
Included accessories: ATEX 3-pole cable entry, stainless steel screws and clamps for surface mounting, stainless steel hooks for suspended mounting.
The driver (electronic ballast) is included in the product and complies with the relevant standards.
The lighting fixture is manufactured in accordance with the requirements of standards SR EN 60079-0, SR EN 60079-31, SR EN 60598-1.
Color: Gray.

Application Area
Lighting in environments with potentially explosive atmospheres, Zone 22. Ambient temperature: -25°C to +45°C.

Light Source Used
LED modules with neutral white color temperature (4000K), CRI 80, with a lifetime at Ta = 25ºC of L80B10 > 80,000 hours
